Description
PLATFORM HIGHLIGHTS
2
ARCHITECTURE
28
PRODUCT WEIGHT
130
MAX USER WEIGHT
20
MAX SPEED
321
RATED POWER
HS-203
KEY FEATURES

Eletectromagnetic safety brakes
Equipped with electromagnetic motor shaft brakes ensures zero movement of the platform when the system is switched off

Software support
Compatible with all major racing and flight titles on PC with simple USB plug in

VR technology
VR Headway technology built into the Platform Manager Software.
For VR companies developing their own software, SDK is available

Fast and smooth realistic movements
Realistic super smooth operation using advanced actuator speed management

Safety
Built in power source, including an active PFC function to protect from short circuit, overload, overvoltage and overheating

Super silent
Acoustical panels inside to reduce noise of operation

Compact design
Additional space in the existing cockpit is not required

Cooling system
Passive and active cooling method with adaptive fan speed control
MOTION PLATFORM HS-203
THE MOST AUTHENTIC AND IMMERSIVE SIMULATION EXPERIENCE
The HS-203 motion platform is entirely designed for customers expecting incredible precision and highest level of immersion. Product is the direct successor to the HS-202 and HS-201 platforms but is has been engineered to be faster and more compact. The seat mover comes with our Platform Manager, which is specialized software for the platform and is plug and play compatible with all major racing and flight titles on PC and constantly updated to support new titles as they are released.
The unit is dedicated for applications where only seat movements are required. The motion system is not only used by sim racers but also leading universities, military defense force, training institutions and professional drivers and pilots.
- gaming and entertainment
- VR projects
- serious games application for land and air simulation
- therapeutic support equipment
- professional SimRacing
GENERAL SPECIFICATION
System performance
Max Angular Displacement for Pitch & Roll
-10.0°, 10.0°
Max Speed
20°/s
Storage temperatures
+4°C to +45°C
Full performance temperatures
+5°C to +35°C
Payload specification
Min user weight
30 kg
Max user weight
130 kg
Product weight
28 kg
Main dimensions
Total width
350 mm
Total height
200 mm
Total length
460 mm
Power requirements
Power source
4A/115VAC, 2A/230VAC
Rated power
321 W
Inrush current
20A/115VAC, 40A/230VAC
Protection class
1
Built-in Power Supply Specification
Active PFC function
Protections
Short circuit/Overload/Over voltage/Over temperature
Power supply certificates

PRODUCT OVERVIEW


PRODUCT REVIEWS
Check following reviews and dedicated Race Department Forum thread for first-hand feedback.
King of the silence
“Another category it not only does well in, but is a class leader in, is noise level. This V3 is unbelievably quiet!”
Inside Sim RacingJohn Sabol
