PS-3TM-LP550

 12 000.00 *

Payload: 550kg
Applications: Lightweight closed cabin units, low profile version
Heave: -0.16, 0.16 m, 4 m/s²
Pitch: -12.0°, 13.7°, 250°/s²
Roll: -11.0°, 11.0°, 250°/s²
Weight: 436kg

PS-3TM-LP550
PROFESSIONAL SERIES
ASK ABOUT PRODUCT

*tax and duty not incl.

€ 12 000.00 *

PLATFORM HIGHLIGHTS

3

ARCHITECTURE

550

PAYLOAD

31

MIN HEIGHT

436

WEIGHT

MOTION PLATFORM

PS-3TM-LP550

PROFESSIONAL SERIES

3

ARCHITECTURE

550

PAYLOAD

31

MIN HEIGHT

436

WEIGHT

ASK ABOUT PRODUCTASK ABOUT PRODUCT

KEY FEATURES

Reliability

High durability and cost-effective operation

Compact design

Super low profile, small footprint and lightweight body

Safety

Safe mechanical design resistant to electronic failures. Safety Integrity Level up to 3

Unleashed performance

Impressive dynamics and performance

VR technology

All our motion platforms work in VR environment

Super Silent

Extremely quiet and smooth operation

Warranty

Global technical support and gear lifetime up to 10 years of operation

Software support

Control all our motion platforms using one of ours SDK

MOTION PLATFORM PS-3TM-LP550

POWERFUL LOWRIDER

The PS-3TM-LP550 is our low-profile, 3DoF product, which is adapted for installation of medium size cockpits and cabins. Motion platform is suitable for full flight cabin mounting on upper frame.
This is great and safety solution for everyone who needs to compact design with impressive dynamics and performance in professional training or entertainment.

  • platforms are suitable for small and medium size flight and land simulators
  • small and medium size full cockpit simulation systems
  • vehicle training simulators for up to 2 people
  • small and medium size military training simulators for up to 2 people
  • small and medium size mining equipment simulators
  • industrial testing
  • virtual reality for entertainment for 2 persons

GENERAL SPECIFICATION

System performance

EXCURSIONS

Velocity

Acceleration

SINGLE DOF

NON-SINGLE DOF

Heave

SINGLE DOF

-0.16, 0.16 m

NON-SINGLE DOF

-0.16, 0.16 m

Velocity

0,276 °/s

Acceleration

4 m/s²

Roll

SINGLE DOF

-11.0°, 11.0°

NON-SINGLE DOF

-22.1°, 22.1°

Velocity

18 °/s

Acceleration

250°/s²

Pitch

SINGLE DOF

-12.0°, 13.7°

NON-SINGLE DOF

-25.8°, 25.8°

Velocity

22 °/s

Acceleration

250°/s²

Payload specification

Payload

550 kg

Product weight

436 kg

Main diemensions

Total width

1802 mm

MIN height

306 mm

Total length

1599 mm

Power requirements

Max power consumption

5,5 kW 19 Amps

System power

200-250 VAC Single Phase

Anchoring

Anchoring

not required for small simulator otherwise anchoring are required (floor footprints points are specified in the blueprints)

DOWNLOAD DATASHEETDOWNLOAD DATASHEETWORK ENVELOPESWORK ENVELOPES

PRODUCT OVERVIEW

ADD-ONS & ACCESSORIES

POWER CABINET

PS-SB230

Power cabinets PS-SB230 are integrated continuous power supply solutions for all our motion platforms. New generation of electrical cabinet is equipped with proprietary design electronics and software. The switch box is responsible for power distribution and acts as safety and control device.

It contains AC and DC fuses and handles remote safety switches also provides power to inverters and motion controller. Design of cabinets allows users to achieve security measures CL class up to SIL(Safety Integrity Level) 3 if required. Additional remote control unit is provided for operator convenience and safety. It allows to start the motion platform, park and stop it immediately in case of emergency situation.

€ 1500.00 (tax and duty not incl.)

ASK ABOUT PRODUCTASK ABOUT PRODUCT
PS-SB-230

ELECTROMAGNETIC SAFETY BRAKES

One set of electromagnetic safety brakes is a protection feature incorporated into our motion platforms. The product is necessary part of motion platforms power supplying set and enables maintaining appropriate SIL (Safety Integrity Level).

€ 360.00 (tax and duty not incl.)

ASK ABOUT PRODUCTASK ABOUT PRODUCT

ADD-ONS & ACCESSORIES

POWER CABINET

PS-SB230

PS-SB-230

Power cabinets PS-SB230 are integrated continuous power supply solutions for all our motion platforms. New generation of electrical cabinet is equipped with proprietary design electronics and software. The switch box is responsible for power distribution and acts as safety and control device.

It contains AC and DC fuses and handles remote safety switches also provides power to inverters and motion controller. Design of cabinets allows users to achieve security measures CL class up to SIL(Safety Integrity Level) 3 if required. Additional remote control unit is provided for operator convenience and safety. It allows to start the motion platform, park and stop it immediately in case of emergency situation.

€ 1500.00 (tax and duty not incl.)

ASK ABOUT PRODUCTASK ABOUT PRODUCT

ELECTROMAGNETIC SAFETY BRAKES

One set of electromagnetic safety brakes is a protection feature incorporated into our motion platforms. The product is necessary part of motion platforms power supplying set and enables maintaining appropriate SIL (Safety Integrity Level).

€ 360.00 (tax and duty not incl.)

ASK ABOUT PRODUCTASK ABOUT PRODUCT

SOFTWARE - FAQ

Even most advanced hardware is nothing without good software. It might looks simple from the outside, but under the hood there is a lot going on, in both firmware and PC software. For instance, we monitor motion stream characteristic and adjust frequency inverters parameters on the fly to make sure that motion platforms is smooth when it is required or fast and brutal in other cases.

WHAT KIND OF SOFTWARE DO I GET?

Every our motion platform is delivered with the platform manager. This application is free of charge for every customers who buys our motion platforms. This rules all to both home and professional series motion platforms. The application allows to use motion platforms with supported games, perform diagnostic, monitor motion platforms operation, update firmware and use SDK - ForceSeatMI to connect it to your custom applications.

CAN I CONTROL MOTION PLATFORM FROM MY SOFTWARE?

You can control all our motion platforms using one of ours SDKs.

IS IT VR READY?

All our motion platforms work in VR environment. Additionally if you need to compensate unwanted head movements caused by motion platform's top frame movements, we have a technology that will do it for you. The VR HeadWay is part of the platform manager and it is available free-of-charge for all customers who bought one of our motion platforms.

WILL IT WORK WITH UNREAL ENGINE 4 AND UNITY?

Both our SDK support both - UE4 and Unity. It means that as long as you can modify UE4/Unity application, you can add support for motion platform to it. Click here for details.

However if you use 3rd party closed source UE4/Unity application or game, then it will not support motion platform by default. Please check with application developers to confirm if they can use our SDKs in their product.

WILL IT WORK WITH LINUX?

The platform manager application supports only Windows PC however our low lever SDK - ForceSeatDI can be used with Linux and Raspberry Pi 3.
