HS-203

Ask for price

Max user weight: 130kg
Applications: Home racing and flights VR simulators
Pitch/roll: ±10°, 20°/s
Weight: 28kg

Categories: , ,

Description

ASK ABOUT PRODUCT
THE MOST COMPACT SOLUTION ON THE MARKET
HS-203

PLATFORM HIGHLIGHTS

2

ARCHITECTURE

28

PRODUCT WEIGHT

130

MAX USER WEIGHT

20

MAX SPEED

321

RATED POWER

MOTION PLATFORM

HS-203

KEY FEATURES

Eletectromagnetic safety brakes

Equipped with electromagnetic motor shaft brakes ensures zero movement of the platform when the system is switched off

Software support

Compatible with all major racing and flight titles on PC with simple USB plug in

VR technology

VR Headway technology built into the Platform Manager Software.
For VR companies developing their own software, SDK is available

Fast and smooth realistic movements

Realistic super smooth operation using advanced actuator speed management

Safety

Built in power source, including an active PFC function to protect from short circuit, overload, overvoltage and overheating

Super silent

Acoustical panels inside to reduce noise of operation

Compact design

Additional space in the existing cockpit is not required

Cooling system

Passive and active cooling method with adaptive fan speed control

MOTION PLATFORM HS-203

THE MOST AUTHENTIC AND IMMERSIVE SIMULATION EXPERIENCE

The HS-203 motion platform is entirely designed for customers expecting incredible precision and highest level of immersion. Product is the direct successor to the HS-202 and HS-201 platforms but is has been engineered to be faster and more compact. The seat mover comes with our Platform Manager, which is specialized software for the platform and is plug and play compatible with all major racing and flight titles on PC and constantly updated to support new titles as they are released.

The unit is dedicated for applications where only seat movements are required. The motion system is not only used by sim racers but also leading universities, military defense force, training institutions and professional drivers and pilots.

  • gaming and entertainment
  • VR projects
  • serious games application for land and air simulation
  • therapeutic support equipment
  • professional SimRacing
We do not sell this product directly to home users. If you are a home user, please contact our global partner. If you need a motion platform for professional application, please contact us to discuss details.

GENERAL SPECIFICATION

System performance

Max Angular Displacement for Pitch & Roll

-10.0°, 10.0°

Max Speed

20°/s

Storage temperatures

+4°C to +45°C

Full performance temperatures

+5°C to +35°C

Payload specification

Min user weight

30 kg

Max user weight

130 kg

Product weight

28 kg

Main dimensions

Total width

350 mm

Total height

200 mm

Total length

460 mm

Power requirements

Power source

4A/115VAC, 2A/230VAC

Rated power

321 W

Inrush current

20A/115VAC, 40A/230VAC

Protection class

1

Built-in Power Supply Specification

Active PFC function

Protections

Short circuit/Overload/Over voltage/Over temperature

Power supply certificates

Power Supply Certifcates

PRODUCT OVERVIEW

PRODUCT REVIEWS

Check following reviews and dedicated Race Department Forum thread for first-hand feedback.

King of the silence

“Another category it not only does well in, but is a class leader in, is noise level. This V3 is unbelievably quiet!”

Inside Sim RacingJohn Sabol
We do not sell this product directly to home users. If you are a home user, please contact our global partner. If you need a motion platform for professional application, please contact us to discuss details.
